Three-in-One Dehumidifying Dryer and Material Fee | RFQ Sourcing Details
Injection Molding Equipment · Quote on request
This is a product procurement detail page: check specs, images, category context and related sourcing paths before sending an RFQ.
Quote on requestProduct specs
Buyer's Digest
Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Injection Molding Equipment. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
This three-in-one unit combines raw-material dehumidification, drying, and two-stage conveying for injection molding operations. Its integrated layout includes a honeycomb rotor dehumidifier, an insulated dryer, and a stainless steel automatic loading machine.
The compact configuration is intended for automated production systems and facilities where installation space is limited. A PLC controller supports equipment operation. The stated drying-air flow range is 25–400 m³/h.
Three listed configurations cover dehumidification capacities of 50, 100, and 150 kg/h, with corresponding conveying capacities of 60, 120, and 180 kg/h. Listed drying-temperature ranges extend from 80–160°C for the SCD-50 to 80–200°C for the SCD-150. All three listed models operate at 380 V.
The equipment is described for preparing polymer raw materials before injection molding. Listed compatible materials include PP, PE, ABS, and PC. Potential production settings include automotive parts, electrical housings, medical-device components, household goods, packaging materials, and engineering-plastic molding.
An optical-grade configuration is also described for optical-product processing. Available model data should be treated as a selection starting point rather than a complete engineering specification.
Before procurement, buyers should confirm the required resin throughput, initial and target moisture levels, drying temperature and residence time, conveying distance and lift, hopper capacity, plant voltage and frequency, cooling-water requirements, compressed-air requirements, connection sizes, controls integration, and installation footprint.
Buyers should also request confirmation that the selected configuration matches the specific resin grade and injection molding machine. Custom configurations are stated to be available.
The listed package dimensions are 300 × 220 × 250 cm with a gross weight of 200 kg, but buyers should verify whether these figures apply to the selected model and included accessories.
The stated standard warranty is 12 months or 2,000 operating hours, whichever occurs first;buyers should confirm the final warranty scope, exclusions, service location, spare-parts coverage, commissioning responsibilities, and training arrangements in the purchase documents.
Three-in-One | Applications and Buyer Notes
Three-in-One is organized as a sourcing-ready Injection Molding Equipment reference. The page combines visible product or company data with structured procurement cues so buyers can compare application fit, specifications, quantity, quality requirements and le
Applications
- Initial shortlist building for related product or supplier options.
- Specification and application fit review before bulk purchasing.
- Category, keyword and detail-page comparison before sending an RFQ.
Key specifications
- Category
- Injection Molding EquipmentBased on visible page data; confirm exact value in the RFQ.
- Unit
- setBased on visible page data; confirm exact value in the RFQ.
- Color
- CustomizableBased on visible page data; confirm exact value in the RFQ.
- SCD-50
- 50 kg/h dehumidification;80–160°C;60 kg/h conveying;12 kW;380 VBased on visible page data; confirm exact value in the RFQ.
- SCD-100
- 100 kg/h dehumidification;80–180°C;120 kg/h conveying;22 kW;380 VBased on visible page data; confirm exact value in the RFQ.
- SCD-150
- 150 kg/h dehumidification;80–200°C;180 kg/h conveying;35 kW;380 VBased on visible page data; confirm exact value in the RFQ.
- Condition
- NewBased on visible page data; confirm exact value in the RFQ.
- Customization
- AvailableBased on visible page data; confirm exact value in the RFQ.
Buyer tips
- State quantity range and split-delivery needs before price comparison.
- Add certification, material or inspection standards when they affect acceptance.
- For time-sensitive projects, include target arrival date and destination.
- For special applications, describe operating condition, installation environment and duty cycle.
FAQ
What should buyers confirm first?
Confirm application, specification, quantity, destination and lead-time requirements before comparing offers.
Can buyers inquire when specs are incomplete?
Yes. Add model, material, size, use case and inspection needs in the RFQ to make replies comparable.
How should this listing be evaluated?
Check title, category, specifications and related keywords against the actual sourcing requirement.
